Super li · VSF claim · 11-photo dealer QC

VSF Submariner Date · 6X05C935

GL candidate · automated visual QC

S001 · Camera geometry corrected. Image rotated approximately 0.5° clockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using the printed ticks’ inner tips after broad ink detection. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Visible dial QC is acceptable, with small image-only luminous-bar offsets rather than perfect straightness. Hands and the displayed date show no compelling defect.

Dial alignment and luminous bars

Visible markers sit coherently against the minute track. Validated S001 luminous-component axes show small offsets at 6 o'clock (-0.1°) and 9 o'clock (-1.9°). The 4 o'clock marker is partly covered by the minute hand. Acceptable visible alignment with a modest local 9 o'clock offset; these image-model results do not measure metal-frame mounting.

S001 S002 S003

Hands, printing and date

Hands appear intact and date 13 is legible without obvious clipping. Hands and shadows cross portions of the printing in different views; no persistent malformed character is established. Visible presentation is acceptable.

S001 S002 S003

Raised bezel

Visible numerals and neighboring ticks show no compelling local spacing defect. Upper-sector glare and tilted views limit assessment. No independently corroborated bezel defect is established.

S001 S002 S003

Exterior finish

Exterior reviews describe protective coverings and a small dark rectangular case-flank mark in S005. Its nature and depth are not established. The isolated mark could be residue, a label or reflection; confirmed finish damage is not supported.

S004 S005 S006 S007 S008

Timegrapher snapshot

Rate +4 s/day; Amplitude 302 °; Beat error 0.2 ms; Lift angle 59 °; Beat rate 28800 bph Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S011

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S001 · Native full-bezel context. Raised bezel and pearl assessed visually in this original camera view

S011 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Position and angle checks

1 dial views · 12 checks

S001 · 1 o’clock

Round feature · position check; no unique axis · centre offset +0.1° from clock ray (segmentation +0.1° to +0.2°) · image-plane only · Complete round luminous marker visible without occlusion.

S001 · 2 o’clock

Round feature · position check; no unique axis · centre offset -0.0° from clock ray (segmentation -0.1° to +0.0°) · image-plane only · Complete round luminous marker visible without occlusion.

S001 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window aperture displaying numeral 13 without luminous material.

S001 · 4 o’clock

Angle unverified · feature edges uncertain · Round luminous marker partially occluded by the minute hand.

S001 · 5 o’clock

Round feature · position check; no unique axis · centre offset -0.0° from clock ray (segmentation -0.1° to +0.3°) · image-plane only · Complete round luminous marker visible without occlusion.

S001 · 6 o’clock

-0.1° luminous image axis · sensitivity -0.2° to +0.5° · centre offset -0.1° from clock ray (segmentation -0.1° to -0.0°) · image-plane only · Complete vertical rectangular luminous baton visible without occlusion.

S001 · 7 o’clock

Round feature · position check; no unique axis · centre offset +0.1° from clock ray (segmentation +0.0° to +0.2°) · image-plane only · Complete round luminous marker visible without occlusion.

S001 · 8 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (segmentation +0.2° to +0.3°) · image-plane only · Complete round luminous marker visible without occlusion.

S001 · 9 o’clock

-1.9° luminous image axis · sensitivity -2.8° to -1.9° · centre offset -0.6° from clock ray (segmentation -0.7° to -0.0°) · image-plane only · Complete horizontal rectangular luminous baton visible without occlusion.

S001 · 10 o’clock

Round feature · position check; no unique axis · centre offset +0.4° from clock ray (segmentation +0.3° to +0.5°) · image-plane only · Complete round luminous marker visible without occlusion.

S001 · 11 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (segmentation +0.2° to +0.3°) · image-plane only · Complete round luminous marker visible without occlusion.

S001 · 12 o’clock

Triangular insert · centre placement; precise rotation unmeasured · centre offset -0.2° from clock ray (segmentation -0.2° to -0.1°) · image-plane only · Complete triangular downward-pointing luminous marker visible without occlusion.

Source gallery

11 photos · 0 videos

11 photos · 0 videos in the saved gallery. Repeated views are not independent confirmation.
