Pingfan · recent gallery · blue/black bezel · Jubilee

VS GMT-Master II · 6X06D071

GL candidate · automated visual QC

S004 · Camera geometry corrected. Image rotated approximately 0.9° counterclockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using isolated printed minute strokes. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Acceptable visible QC in the supplied photos. Dial placement looks coherent; the 9 o’clock luminous bar has a small image-only axis offset, not a demonstrated mounting defect.

Dial placement and 9 o’clock bar axis

The validated S004 track fit supports coherent visible marker placement. The complete 9 o’clock luminous component has an axis offset of -0.9° (geometry-plus-segmentation sensitivity -1.2° to -0.8°). Its placement offset is separately 0.3° (sensitivity 0.2° to 0.3°). This is a small image-only luminous-axis offset, not perfect straightness or a measurement of metal-frame mounting.

S004 S005 S008

Covered lower markers

The 6 o’clock luminous component is crossed by sticker graphics and edges in S004 and S007; other supplied views retain that covering. The S004 diagnostic explicitly vetoes its axis and placement. Portions of the 7 and 8 o’clock markers are also covered. Repeated descriptions of a lean do not overcome the repeated physical occlusion.

S004 S005 S006 S007 S008

Hands, printing and date

Visible hands appear intact and the displayed date 9 is legible without obvious clipping. Hands and the sticker cover portions of the dial lettering. No malformed-text claim is supported at covered characters.

S004 S005 S006 S007 S008

Raised bezel

Native views show the triangle, numerals, adjacent bezel dots and two-colour insert without an obvious repeated local spacing anomaly. Reflections alter the apparent black/blue boundary in several views. No consequential bezel defect is corroborated.

S004 S006 S007 S008

Exterior finish

Exposed case and bracelet areas show no obvious major damage. Wrinkled protective film and reflections cover substantial surfaces. Visible finish is acceptable, but concealed scratches or marks cannot be excluded.

S004 S007 S008

Timegrapher snapshot

Rate +7 s/day; Amplitude 223 °; Beat error 0 ms; Lift angle 52 ° Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S020

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S004 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S020 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Position and angle checks

1 dial views · 12 checks

S004 · 1 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.1°) · image-plane only · Round marker visible without occlusion.

S004 · 2 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.3°) · image-plane only · Round marker visible without occlusion.

S004 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window visible under cyclops magnifier.

S004 · 4 o’clock

Round feature · position check; no unique axis · centre offset +0.4° from clock ray (geometry + segmentation +0.4° to +0.5°) · image-plane only · Round marker visible without occlusion.

S004 · 5 o’clock

Angle unverified · feature edges uncertain · Round marker visible without occlusion.

S004 · 6 o’clock

Angle unverified · feature edges uncertain · Baton marker partially occluded by print overlay.

S004 · 7 o’clock

Round feature · position check; no unique axis · Round marker partially covered by circular graphic overlay.

S004 · 8 o’clock

Angle unverified · feature edges uncertain · Round marker partially occluded by GMT hand tip.

S004 · 9 o’clock

-0.9° luminous image axis · sensitivity -1.2° to -0.8° (geometry + segmentation; not physical tilt) · centre offset +0.3° from clock ray (geometry + segmentation +0.2° to +0.3°) · image-plane only · Elongated baton marker clearly visible.

S004 · 10 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Round marker visible without occlusion.

S004 · 11 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Round marker visible without occlusion.

S004 · 12 o’clock

Triangular insert · centre placement; precise rotation unmeasured · centre offset -0.1° from clock ray (geometry + segmentation -0.2° to -0.1°) · image-plane only · Triangular lume marker visible without obstruction.

Source gallery

20 photos · 0 videos

20 photos · 0 videos in the saved gallery. Repeated views are not independent confirmation.
