Gallery QC

VS 40绿水鬼 6R07A629

GL candidate · automated visual QC

S004 · Camera geometry corrected. Image rotated approximately 0.0° clockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using isolated printed minute strokes. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Visible QC is acceptable with a small, repeated image-only offset of the 9 o’clock luminous insert. The 12 o’clock triangle shows no convincing tilt; the suspected 6 o’clock lean is obscured by the minute hand.

Dial placement and 9 o’clock insert axis

The visible dial layout is balanced. The 9 o’clock luminous insert has a small repeated axis offset: S004 1.3° (sensitivity 1.1° to 1.4°); S019 1.4° (1.3° to 1.4°). Its placement is separately near the radial reference: S004 -0.1° (-0.1° to -0.1°); S019 0.1° (0.1° to 0.2°). Native pixels and completed diagnostics support the luminous-component axes, not a calibrated metal-frame mounting angle.

S004 S019 S020

12 o’clock triangle orientation

S004 and S019 native triangle close-ups show approximately level top edges and apex-to-base relationships without a convincing repeated lean. Their corrected edge views support that assessment; S019 has strong purple/blue reflection along the insert and frame. The orientation review is supported visually, rather than dismissed using centroid placement or absent rectangular-axis measurements.

S004 S019 S020

6 o’clock suspected lean

The minute hand covers a substantial part of the 6 o’clock luminous baton in S004, S019 and S020. The S019 speculative lean cannot be reliably separated from that overlap. Both axis and placement are withheld.

S004 S019 S020

Hands, printing and date

Visible hand surfaces and dial printing show no convincing damage or malformed text. Hands cover portions of the logo and lower lettering. The displayed date 5 is readable and adequately contained in the aperture. Covered letters are unverified, not malformed.

S004 S019 S020

Raised bezel

Native bezel views show intact visible markings without a convincing locally misplaced numeral or tick. Perspective and reflections affect the raised surface. No consequential bezel-spacing or alignment defect is independently supported.

S004 S019 S020

Exterior finish and clasp marks

S017 shows fine linear marks on reflective clasp surfaces with apparent protective covering. Visible case surfaces in S004 are also affected by film and reflections. Persistent scratches beneath the covering are not established; this isolated finish concern is not grounds for HOLD.

S017 S004

Timegrapher snapshot

Rate -2 s/day; Amplitude 260 °; Beat error 0 ms; Lift angle 52 ° Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S021

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S004 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S004 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S019 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S021 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Supporting dial views

Additional camera references

S019

Camera geometry corrected

Position and angle checks

2 dial views · 24 checks

S004 · 1 o’clock

Round feature · position check; no unique axis · centre offset -0.0° from clock ray (geometry + segmentation -0.1° to +0.0°) · image-plane only · Round luminous marker is unobstructed with clean mask.

S004 · 2 o’clock

Round feature · position check; no unique axis · centre offset -0.1° from clock ray (geometry + segmentation -0.2° to -0.0°) · image-plane only · Round luminous marker is unoccluded and fully masked.

S004 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window aperture rather than a luminous marker.

S004 · 4 o’clock

Round feature · position check; no unique axis · centre offset -0.4° from clock ray (geometry + segmentation -0.4° to -0.2°) · image-plane only · Circular luminous plot is clear of hands and cleanly segmented.

S004 · 5 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.1°) · image-plane only · Round luminous marker is fully visible without occlusion.

S004 · 6 o’clock

Angle unverified · feature edges uncertain · Elongated baton marker is partially occluded by the minute hand.

S004 · 7 o’clock

Round feature · position check; no unique axis · Round luminous marker is partially occluded by the seconds hand.

S004 · 8 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.5° to -0.2°) · image-plane only · Round luminous marker is unoccluded and properly segmented.

S004 · 9 o’clock

+1.3° luminous image axis · sensitivity +1.0° to +1.4° (geometry + segmentation; not physical tilt) · centre offset -0.1° from clock ray (geometry + segmentation -0.1° to -0.1°) · image-plane only · Rectangular baton luminous insert is fully unoccluded and cleanly isolated.

S004 · 10 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation +0.0° to +0.3°) · image-plane only · Round luminous plot is fully clear of obstruction.

S004 · 11 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation +0.3° to +0.4°) · image-plane only · Round luminous insert is clean and fully segmented.

S004 · 12 o’clock

Triangular insert · centre placement; precise rotation unmeasured · centre offset +0.3° from clock ray (geometry + segmentation -0.1° to +0.4°) · image-plane only · Luminous coverage verified; this is not a straightness pass. · Final triangle finding: 12 o’clock triangle orientation. S004 and S019 native triangle close-ups show approximately level top edges and apex-to-base relationships without a convincing repeated lean.

S019 · 1 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation +0.3° to +0.4°) · image-plane only · Round luminous marker fully isolated without occlusion.

S019 · 2 o’clock

Round feature · position check; no unique axis · centre offset -0.1° from clock ray (geometry + segmentation -0.1° to +0.0°) · image-plane only · Round luminous marker fully captured by mask.

S019 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window aperture with numeral, not a luminous marker.

S019 · 4 o’clock

Round feature · position check; no unique axis · centre offset -0.6° from clock ray (geometry + segmentation -0.7° to -0.5°) · image-plane only · Round luminous marker with intact segmentation.

S019 · 5 o’clock

Round feature · position check; no unique axis · centre offset -0.1° from clock ray (geometry + segmentation -0.2° to +0.0°) · image-plane only · Round luminous marker fully isolated and unoccluded.

S019 · 6 o’clock

Angle unverified · local axis not confirmed · Elongated luminous marker partially occluded by the minute hand.

S019 · 7 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation +0.2° to +0.6°) · image-plane only · Round luminous marker clearly visible and fully masked.

S019 · 8 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Round luminous marker unoccluded with complete mask.

S019 · 9 o’clock

+1.4° luminous image axis · sensitivity +1.3° to +1.4° (geometry + segmentation; not physical tilt) · centre offset +0.1° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Elongated rectangular luminous baton fully visible and properly segmented.

S019 · 10 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Round luminous marker unoccluded with complete mask.

S019 · 11 o’clock

Angle unverified · feature edges uncertain · Round luminous marker has an incomplete mask missing a section on the left.

S019 · 12 o’clock

Angle unverified · local axis not confirmed · centre offset +3.9° from clock ray (geometry + segmentation +3.8° to +3.9°) · image-plane only · Luminous coverage verified; this is not a straightness pass. · Final triangle finding: 12 o’clock triangle orientation. S004 and S019 native triangle close-ups show approximately level top edges and apex-to-base relationships without a convincing repeated lean.

Source gallery

21 photos · 0 videos

21 photos · 0 videos in the saved gallery. Repeated views are not independent confirmation.
