Gallery QC

VS 36绿恒动 6X018776

GL candidate · automated visual QC

S004 · Camera geometry corrected. Image rotated approximately 0.0° clockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using isolated printed minute strokes. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Visible QC is acceptable overall, with a small repeated lean of the 11 o’clock luminous insert noted as a minor concern, not a confirmed metal-frame mounting defect. Dial printing, hands and smooth bezel show no compelling defect.

Dial alignment and local marker axes

Dial layout and printing look orderly. The 11 o’clock luminous insert shows a small repeated image-axis lean in S004 and S019. Other local offsets are less consistent across views; the 4 o’clock result changes direction. S007 obscures the 11 o’clock insert with the seconds hand. The repeated 11 o’clock offset merits a minor cosmetic note rather than a claim of perfect straightness.

S004 S019 S007

Marker placement and withheld features

Validated track fits support broadly coherent marker placement, with small local placement offsets distinct from insert-axis lean. Double-marker segmentation at 3, 6 and 9 is incomplete; the coronet is not an elongated luminous bar. Placement does not test straightness.

S004 S019 S007

Hands, text and date

Visible hands and dial lettering show no compelling damage or malformed characters. The seconds hand crosses lettering and a marker in S007. Supplied dial pixels show a double marker at 3 o’clock, not a date window, contrary to the S010 review. Occlusion is not a printing defect.

S004 S019 S007 S010

Bezel and exterior finish

The smooth polished bezel shows strong reflections but no corroborated damage. Visible case and bracelet surfaces retain protective film. No bezel numeral, colour-transition or pearl alignment test applies.

S004 S019 S007

Timegrapher snapshot

Rate +3 s/day; Amplitude 217 °; Beat error 0 ms; Lift angle 52 °; Beat rate 28800 bph Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S020

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S004 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S020 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Supporting dial views

Additional camera references

S019

Camera geometry corrected

S007

Camera geometry corrected

Position and angle checks

3 dial views · 36 checks

S004 · 1 o’clock

Angle unverified · feature edges uncertain · centre offset +0.4° from clock ray (geometry + segmentation +0.3° to +0.4°) · image-plane only · Complete rectangular luminous baton with unobstructed view.

S004 · 2 o’clock

Angle unverified · feature edges uncertain · Single complete luminous bar clearly segmented. · amber outlines are candidate reflective edges

S004 · 3 o’clock

Angle unverified · local axis not confirmed · Double baton marker with only top segment masked. · amber outlines are candidate reflective edges

S004 · 4 o’clock

-0.6° luminous image axis · sensitivity -1.6° to -0.3° (geometry + segmentation; not physical tilt) · centre offset +0.1° from clock ray (geometry + segmentation -0.0° to +0.2°) · image-plane only · Complete luminous insert without notable occlusion. · amber outlines are candidate reflective edges

S004 · 5 o’clock

Angle unverified · feature edges uncertain · Fully masked luminous baton marker. · amber outlines are candidate reflective edges

S004 · 6 o’clock

Angle unverified · local axis not confirmed · Double baton element with right segment isolated. · amber outlines are candidate reflective edges

S004 · 7 o’clock

Angle unverified · feature edges uncertain · Complete luminous segment visible without occlusion. · amber outlines are candidate reflective edges

S004 · 8 o’clock

Angle unverified · feature edges uncertain · centre offset +0.3° from clock ray (geometry + segmentation +0.1° to +0.4°) · image-plane only · Fully isolated luminous bar with intact edges.

S004 · 9 o’clock

Angle unverified · local axis not confirmed · Double baton partially occluded across lower bar by seconds hand. · amber outlines are candidate reflective edges

S004 · 10 o’clock

Angle unverified · feature edges uncertain · Complete luminous bar clear of any obstructions. · amber outlines are candidate reflective edges

S004 · 11 o’clock

-1.7° luminous image axis · sensitivity -1.9° to -1.5° (geometry + segmentation; not physical tilt) · centre offset +0.6° from clock ray (geometry + segmentation +0.5° to +0.6°) · image-plane only · Unoccluded complete luminous insert.

S004 · 12 o’clock

Angle unverified · feature edges uncertain · Applied coronet logo without luminous insert.

S019 · 1 o’clock

Angle unverified · feature edges uncertain · Single rectangular luminous baton visible and fully segmented with no occlusion. · amber outlines are candidate reflective edges

S019 · 2 o’clock

Angle unverified · feature edges uncertain · Single rectangular luminous baton visible and clearly segmented. · amber outlines are candidate reflective edges

S019 · 3 o’clock

Angle unverified · feature edges uncertain · Double baton marker partially occluded by the minute hand, with incomplete mask segmentation. · amber outlines are candidate reflective edges

S019 · 4 o’clock

+0.9° luminous image axis · sensitivity +0.6° to +1.9° (geometry + segmentation; not physical tilt) · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Single rectangular luminous baton visible and fully segmented without occlusion. · amber outlines are candidate reflective edges

S019 · 5 o’clock

+1.3° luminous image axis · sensitivity +0.4° to +1.4° (geometry + segmentation; not physical tilt) · centre offset +0.1° from clock ray (geometry + segmentation -0.0° to +0.1°) · image-plane only · Single rectangular luminous baton visible and completely isolated in the mask. · amber outlines are candidate reflective edges

S019 · 6 o’clock

Angle unverified · feature edges uncertain · Double baton marker where only the right bar is masked, missing the full dual-marker geometry. · amber outlines are candidate reflective edges

S019 · 7 o’clock

-0.9° luminous image axis · sensitivity -1.0° to -0.4° (geometry + segmentation; not physical tilt) · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.1°) · image-plane only · Single rectangular luminous baton fully unoccluded and cleanly segmented. · amber outlines are candidate reflective edges

S019 · 8 o’clock

Angle unverified · feature edges uncertain · Single rectangular luminous baton clearly visible and fully captured by the mask. · amber outlines are candidate reflective edges

S019 · 9 o’clock

Angle unverified · local axis not confirmed · Double baton marker where only the top bar is segmented, leaving the dual element incomplete. · amber outlines are candidate reflective edges

S019 · 10 o’clock

Angle unverified · feature edges uncertain · Single rectangular luminous baton unobstructed and fully segmented.

S019 · 11 o’clock

-2.6° luminous image axis · sensitivity -2.8° to -2.4° (geometry + segmentation; not physical tilt) · centre offset +0.7° from clock ray (geometry + segmentation +0.7° to +0.7°) · image-plane only · Single rectangular luminous baton clearly visible and cleanly segmented. · amber outlines are candidate reflective edges

S019 · 12 o’clock

Angle unverified · feature edges uncertain · Applied coronet logo lacking luminous insert, with an uncertifiable outline mask.

S007 · 1 o’clock

-2.6° luminous image axis · sensitivity -2.9° to -1.6° (geometry + segmentation; not physical tilt) · centre offset +0.4° from clock ray (geometry + segmentation +0.3° to +0.4°) · image-plane only · Single baton marker fully captured without occlusion.

S007 · 2 o’clock

Angle unverified · feature edges uncertain · Single baton marker fully captured without occlusion.

S007 · 3 o’clock

Angle unverified · feature edges uncertain · Double baton marker with only top bar segmented. · amber outlines are candidate reflective edges

S007 · 4 o’clock

-0.9° luminous image axis · sensitivity -2.2° to -0.2° (geometry + segmentation; not physical tilt) · centre offset +0.4° from clock ray (geometry + segmentation +0.3° to +0.5°) · image-plane only · Single baton marker fully captured without occlusion. · amber outlines are candidate reflective edges

S007 · 5 o’clock

Angle unverified · feature edges uncertain · Single baton marker fully captured without occlusion. · amber outlines are candidate reflective edges

S007 · 6 o’clock

Angle unverified · feature edges uncertain · Double baton marker with only right bar segmented. · amber outlines are candidate reflective edges

S007 · 7 o’clock

Angle unverified · feature edges uncertain · Single baton marker fully captured without occlusion.

S007 · 8 o’clock

Angle unverified · feature edges uncertain · Single baton marker fully captured without occlusion. · amber outlines are candidate reflective edges

S007 · 9 o’clock

Angle unverified · feature edges uncertain · Double baton marker with only bottom bar segmented. · amber outlines are candidate reflective edges

S007 · 10 o’clock

+2.9° luminous image axis · sensitivity +2.8° to +3.0° (geometry + segmentation; not physical tilt) · centre offset -0.1° from clock ray (geometry + segmentation -0.1° to -0.1°) · image-plane only · Single baton marker fully captured without occlusion.
