Gallery QC

RWF Daytona Le Mans · OXJ24250

GL candidate · automated visual QC

S013 · Camera geometry corrected. Image rotated approximately 0.8° clockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using isolated printed minute strokes. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Acceptable visible photo QC. Dial placement appears coherent; small luminous-insert axis offsets are image-only observations, not confirmed metal-frame mounting defects.

Dial placement and local marker axes

S013 shows coherent marker placement against the minute track. Its validated luminous-component axes have small visible offsets: for example, 1 o’clock -1.9° with sensitivity -2.6° to -1.6°, and 2 o’clock 2.5° with sensitivity 2.1° to 2.7°. Placement is separate: respectively -0.2° (-0.4° to -0.2°) and -0.2° (-0.4° to -0.1°). These are image-only luminous-insert results, not metal-frame mounting measurements.

S013 S003 S004 S005

Hands, printing and date

Visible hands appear intact. The central hand crosses the upper dial lettering; other hands cover portions of subdial printing and the 4 o’clock marker. No date window is visible in this layout. Covered characters do not establish malformed text.

S013

Raised tachymeter bezel

The native S013 view shows legible bezel markings without an obvious local numeral-to-adjacent-tick spacing defect. Tilt and strong reflections affect the raised surface. No consequential bezel defect is established.

S013

Case, bracelet and finish

Visible exterior surfaces show substantial reflections and protective material. Exterior reviews report no clear major finish issue. No supported major damage is established, but film, glare and limited supplied native exterior pixels prevent confirmation of pristine underlying surfaces.

S013 S008 S009 S010 S011 S014

Seller identity, construction and weight claims

Rear-view reviews describe a visible movement; S015 describes a watch on a scale but supplies no verified weight reading. RWF identity, 4132 construction, free-sprung construction, OXJ24250 and 184 g remain supplied claims rather than independently established facts.

S011 S012 S015

Timegrapher snapshot

Rate +8 s/day; Amplitude 285 °; Beat error 0.4 ms; Lift angle 52 °; Beat rate 28800 bph Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S016

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S013 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S016 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Position and angle checks

1 dial views · 12 checks

S013 · 1 o’clock

-1.9° luminous image axis · sensitivity -2.6° to -1.6° (geometry + segmentation; not physical tilt) · centre offset -0.2° from clock ray (geometry + segmentation -0.4° to -0.2°) · image-plane only · Complete unoccluded luminous baton insert.

S013 · 2 o’clock

+2.5° luminous image axis · sensitivity +2.1° to +2.7° (geometry + segmentation; not physical tilt) · centre offset -0.2° from clock ray (geometry + segmentation -0.4° to -0.1°) · image-plane only · Full luminous baton insert without obstruction. · amber outlines are candidate reflective edges

S013 · 3 o’clock

Angle unverified · feature edges uncertain · centre offset +0.1° from clock ray (geometry + segmentation -0.0° to +0.2°) · image-plane only · Truncated luminous baton insert adjacent to subdial.

S013 · 4 o’clock

Angle unverified · local axis not confirmed · Luminous baton partially occluded by chronograph minute hand.

S013 · 5 o’clock

+0.3° luminous image axis · sensitivity -0.1° to +1.6° (geometry + segmentation; not physical tilt) · centre offset +0.1° from clock ray (geometry + segmentation +0.0° to +0.2°) · image-plane only · Complete unoccluded luminous baton insert. · amber outlines are candidate reflective edges

S013 · 6 o’clock

Angle unverified · feature edges uncertain · Truncated luminous baton insert above Swiss Made text.

S013 · 7 o’clock

+0.5° luminous image axis · sensitivity +0.2° to +0.6° (geometry + segmentation; not physical tilt) · centre offset -0.0° from clock ray (geometry + segmentation -0.2° to +0.1°) · image-plane only · Full luminous baton insert with clear boundaries.

S013 · 8 o’clock

-1.8° luminous image axis · sensitivity -2.2° to -1.5° (geometry + segmentation; not physical tilt) · centre offset +0.1° from clock ray (geometry + segmentation -0.1° to +0.4°) · image-plane only · Complete unobstructed luminous baton insert.

S013 · 9 o’clock

Angle unverified · feature edges uncertain · centre offset -0.2° from clock ray (geometry + segmentation -0.4° to +0.2°) · image-plane only · Truncated luminous baton insert adjacent to hour subdial. · amber outlines are candidate reflective edges

S013 · 10 o’clock

-0.6° luminous image axis · sensitivity -0.8° to -0.4° (geometry + segmentation; not physical tilt) · centre offset -0.3° from clock ray (geometry + segmentation -0.4° to +0.1°) · image-plane only · Complete unoccluded luminous baton insert.

S013 · 11 o’clock

+0.4° luminous image axis · sensitivity +0.3° to +1.1° (geometry + segmentation; not physical tilt) · centre offset -0.1° from clock ray (geometry + segmentation -0.2° to +0.1°) · image-plane only · Full luminous baton insert free of obstruction.
