Juice QC · 17 photos · RICH JH3235 sticker

RICH green-bezel Submariner · P1681002

GL candidate · automated visual QC

S003 · Camera geometry corrected. Image rotated approximately 0.9° counterclockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using isolated printed minute strokes. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Acceptable visible photo QC, with small repeated image-plane offsets in the 6 and 9 o’clock luminous bars—not perfectly straight, but not a compelling mounting defect. Triangle edge evidence does not support a consequential tilt.

Dial placement and bar axes

Dial layout is visually coherent. The 6 o’clock luminous axis shows small repeated offsets: S003 -0.7° [-1.0°, -0.6°], S005 -1.4° [-1.5°, -1.0°], S001 -0.8° [-1.2°, -0.8°]. At 9 o’clock: S003 -0.8° [-1.1°, -0.3°], S005 -1.1° [-1.2°, -0.9°]. Placement is a separate assessment and shows no conspicuous displacement. The S005/6 concern has modest corroboration, rather than being entirely perspective.

S003 S005 S001

12 o’clock triangle orientation

S003/12 native and corrected edges show a broadly level base and balanced convergence toward the apex. S001/12 supports the same appearance at lower resolution. S005/12 has a seconds hand along the left edge; its exposed base and right edge remain consistent with the other views. Neither insert nor metal-frame edge evidence supports a repeated consequential lean.

S003 S001 S005

Printing, hands and date

S003 and S005 show intact-looking hands and a legible date 18. Hands and their shadows cross portions of the dial lettering; the exposed printing shows no clear malformed character. Visible appearance is acceptable.

S003 S005 S006

Raised bezel

Native S003 shows coherent local numeral and tick spacing; S005 and S006 provide tilted, reflective supplementary views. No persistent chip or conspicuous local spacing anomaly is apparent. No consequential bezel defect is supported.

S003 S005 S006

Case, bracelet and clasp finish

S006, S011 and S014 show protective-film wrinkles and reflective artifacts; S014's sticker covers part of the caseback. S012 shows fine clasp lines without clear corroboration as scratches. These do not establish persistent damage.

S006 S011 S012 S014

Timegrapher snapshot

Rate +8 s/day; Amplitude 271 °; Beat error 0.2 ms; Lift angle 52 °; Beat rate 28800 bph; Interval 12 s Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S017

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S003 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S003 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S005 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S001 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S017 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Supporting dial views

Additional camera references

S005

Camera geometry corrected

S001

Camera geometry corrected

Position and angle checks

3 dial views · 36 checks

S003 · 1 o’clock

Round feature · position check; no unique axis · Round marker partially occluded by the minute hand tip with frame bleed.

S003 · 2 o’clock

Round feature · position check; no unique axis · Unoccluded circular luminous marker cleanly isolated.

S003 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Magnified date window aperture without luminous insert.

S003 · 4 o’clock

Round feature · position check; no unique axis · Unoccluded circular luminous marker fully captured.

S003 · 5 o’clock

Round feature · position check; no unique axis · centre offset +0.0° from clock ray (geometry + segmentation -0.0° to +0.2°) · image-plane only · Unoccluded circular luminous marker fully captured.

S003 · 6 o’clock

-0.7° luminous image axis · sensitivity -1.0° to -0.6° (geometry + segmentation; not physical tilt) · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.4°) · image-plane only · Vertical rectangular baton lume unoccluded and cleanly isolated.

S003 · 7 o’clock

Round feature · position check; no unique axis · Unoccluded circular luminous marker cleanly isolated.

S003 · 8 o’clock

Round feature · position check; no unique axis · Unoccluded circular luminous marker cleanly isolated.

S003 · 9 o’clock

-0.8° luminous image axis · sensitivity -1.1° to -0.3° (geometry + segmentation; not physical tilt) · centre offset +0.0° from clock ray (geometry + segmentation +0.0° to +0.1°) · image-plane only · Horizontal rectangular baton lume unoccluded and cleanly isolated.

S003 · 10 o’clock

Round feature · position check; no unique axis · centre offset -0.0° from clock ray (geometry + segmentation -0.1° to +0.0°) · image-plane only · Circular luminous marker unoccluded by nearby hour hand.

S003 · 11 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.1°) · image-plane only · Unoccluded circular luminous marker cleanly isolated.

S003 · 12 o’clock

Triangular insert · centre placement; precise rotation unmeasured · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Luminous coverage verified; this is not a straightness pass. · Final triangle finding: 12 o’clock triangle orientation. S003/12 native and corrected edges show a broadly level base and balanced convergence toward the apex.

S005 · 1 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.4° to +0.3°) · image-plane only · Round luminous marker is clear of hand occlusion.

S005 · 2 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation -0.3° to +0.4°) · image-plane only · Round luminous marker is unoccluded and fully visible.

S005 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date magnification window displaying numerals, non-luminous.

S005 · 4 o’clock

Round feature · position check; no unique axis · Round marker luminous insert was masked out completely.

S005 · 5 o’clock

Round feature · position check; no unique axis · Round luminous marker is fully visible with no occlusion.

S005 · 6 o’clock

-1.4° luminous image axis · sensitivity -1.5° to -1.0° (geometry + segmentation; not physical tilt) · centre offset +0.3° from clock ray (geometry + segmentation +0.0° to +0.4°) · image-plane only · Elongated luminous baton is clear of hands.

S005 · 7 o’clock

Round feature · position check; no unique axis · centre offset -0.5° from clock ray (geometry + segmentation -0.5° to -0.4°) · image-plane only · Round luminous marker is unoccluded.

S005 · 8 o’clock

Round feature · position check; no unique axis · centre offset -0.7° from clock ray (geometry + segmentation -0.8° to -0.6°) · image-plane only · Round luminous marker is clear of hands.

S005 · 9 o’clock

-1.2° luminous image axis · sensitivity -1.3° to -0.9° (geometry + segmentation; not physical tilt) · centre offset +0.0° from clock ray (geometry + segmentation -0.0° to +0.1°) · image-plane only · Elongated luminous baton is completely unoccluded.

S005 · 10 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.2°) · image-plane only · Round luminous marker has slight frame glare but clean insert.

S005 · 11 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.4° to -0.3°) · image-plane only · Round luminous marker is completely unoccluded.

S005 · 12 o’clock

Triangular insert · centre placement; precise rotation unmeasured · Luminous mask incomplete; numerical angle withheld. · Final triangle finding: 12 o’clock triangle orientation. S003/12 native and corrected edges show a broadly level base and balanced convergence toward the apex.

S001 · 1 o’clock

Round feature · position check; no unique axis · Circular luminous plot with partial frame inclusion in the mask.

S001 · 2 o’clock

Round feature · position check; no unique axis · Circular luminous marker with slight edge highlight contamination.

S001 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window aperture showing numeral 17, not a luminous marker.

S001 · 4 o’clock

Round feature · position check; no unique axis · Round luminous plot with minor frame edge inclusion in mask.

S001 · 5 o’clock

Round feature · position check; no unique axis · Round luminous marker with thin edge highlight included.

S001 · 6 o’clock

-0.8° luminous image axis · sensitivity -1.2° to -0.8° (geometry + segmentation; not physical tilt) · centre offset -0.0° from clock ray (geometry + segmentation -0.1° to +0.1°) · image-plane only · Vertical rectangular luminous baton cleanly segmented.

S001 · 7 o’clock

Round feature · position check; no unique axis · Circular luminous plot with partial rim artifact.

S001 · 8 o’clock

Round feature · position check; no unique axis · Circular luminous marker with rim highlight captured in mask.

S001 · 9 o’clock

Angle unverified · local axis not confirmed · Horizontal rectangular luminous baton with thin metal border artifact.

S001 · 10 o’clock

Angle unverified · feature edges uncertain · Round luminous marker partially occluded by seconds hand. · amber outlines are candidate reflective edges
