Gallery QC

RGF 40间金黑水鬼增重 6R6336V6

GL candidate · automated visual QC

S004 · Camera geometry corrected. Image rotated approximately 0.2° counterclockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using detected printed tick centres. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Visible QC is acceptable with small image-only orientation offsets at 6 and 12 o’clock. The repeated 9 o’clock lean reports are not confirmed: the minute hand obscures the insert in the useful views.

Dial placement

The validated track reviews and supplied dial views show a coherent marker layout without conspicuous displacement. Placement is acceptable where visible; it does not establish individual marker straightness.

S004 S019 S006

6 o’clock luminous bar axis

The complete luminous components support small nonzero image-axis offsets: S004 0.5° (sensitivity 0.4° to 0.5°), S019 0.4° (0.4° to 0.7°), and S006 0.5° (0.4° to 0.6°). These are geometry-plus-segmentation sensitivity ranges, not confidence intervals or physical metal-frame mounting angles.

S004 S019 S006

12 o’clock triangle orientation

S004 and S019 native and corrected close-ups show a slightly rising luminous base toward the right and a small apex-to-base-midpoint lean. Their amber contours follow the luminous insert rather than the outer frame. S006’s corrected edges show a similar subtle asymmetry, although its oblique native view is less decisive. The pixels do not support the prose claims of exactly horizontal bases or no discernible deviation.

S004 S019 S006

9 o’clock reported lean

S004, S019, S003 and S001 reviews report an apparent lean. The supplied pixels show minute-hand overlap; S004, S019 and S006 diagnostics explicitly veto the incomplete luminous masks. The repeated prose does not establish repeated unobstructed edge evidence.

S004 S019 S006 S003 S001

Hands, printing and date

Visible hand outlines and luminous fills appear intact. The displayed date 9 is legible without obvious clipping. Hands cover portions of the dial lettering. No malformed-text or visible hand defect is supported.

S004 S019 S006

Bezel and exterior finish

Native bezel views show no conspicuous local numeral-to-adjacent-tick spacing anomaly. Visible case and bracelet surfaces show protective film and reflections without a clearly corroborated major blemish. Bezel assessment is separate from dial correction.

S004 S006 S019 S003

Timegrapher snapshot

Rate +6 s/day; Amplitude 293 °; Beat error 0.2 ms; Lift angle 52 °; Beat rate 28800 bph Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S021

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S004 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S004 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S019 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S006 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S021 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Supporting dial views

Additional camera references

S019

Camera geometry corrected

S006

Camera geometry corrected

Position and angle checks

3 dial views · 36 checks

S004 · 1 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.1°) · image-plane only · Round luminous marker is unoccluded.

S004 · 2 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to -0.0°) · image-plane only · Round luminous marker is unobstructed.

S004 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window aperture with cyclops magnification.

S004 · 4 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation -0.2° to +0.2°) · image-plane only · Round luminous marker is clear.

S004 · 5 o’clock

Angle unverified · feature edges uncertain · Round luminous marker partially occluded by second hand.

S004 · 6 o’clock

+0.5° luminous image axis · sensitivity +0.4° to +0.5° (geometry + segmentation; not physical tilt) · centre offset -0.0° from clock ray (geometry + segmentation -0.1° to +0.1°) · image-plane only · Rectangular luminous marker is completely visible.

S004 · 7 o’clock

Round feature · position check; no unique axis · Round luminous marker is unobstructed.

S004 · 8 o’clock

Round feature · position check; no unique axis · centre offset +0.1° from clock ray (geometry + segmentation +0.0° to +0.1°) · image-plane only · Round luminous marker is fully visible.

S004 · 9 o’clock

Angle unverified · local axis not confirmed · Rectangular luminous marker partially occluded by minute hand.

S004 · 10 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.2°) · image-plane only · Round luminous marker is clear.

S004 · 11 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Round luminous marker is unobstructed.

S004 · 12 o’clock

Triangular insert · centre placement; precise rotation unmeasured · centre offset -0.3° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Luminous coverage verified; this is not a straightness pass. · Final triangle finding: 12 o’clock triangle orientation. S004 and S019 native and corrected close-ups show a slightly rising luminous base toward the right and a small apex-to-base-midpoint lean. · Luminous top-edge direction -1.6° (sensitivity -1.7° to -1.4°); apex-to-base direction -1.9° (sensitivity -2.0° to -1.9°). Image-plane silhouette directions, not physical mounting angles or factory tolerances.

S019 · 1 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Unoccluded round luminous plot correctly isolated.

S019 · 2 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Unoccluded round luminous plot cleanly segmented.

S019 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window aperture with cyclops lens magnification, not luminous.

S019 · 4 o’clock

Round feature · position check; no unique axis · centre offset +0.1° from clock ray (geometry + segmentation +0.1° to +0.1°) · image-plane only · Unoccluded round luminous marker with clear mask.

S019 · 5 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation +0.2° to +0.2°) · image-plane only · Unoccluded round luminous plot cleanly segmented.

S019 · 6 o’clock

+0.4° luminous image axis · sensitivity +0.4° to +0.7° (geometry + segmentation; not physical tilt) · centre offset -0.0° from clock ray (geometry + segmentation -0.1° to +0.1°) · image-plane only · Unoccluded rectangular baton marker with complete luminous mask.

S019 · 7 o’clock

Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.3°) · image-plane only · Unoccluded round luminous marker cleanly isolated.

S019 · 8 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation +0.2° to +0.4°) · image-plane only · Unoccluded round luminous plot with clear mask.

S019 · 9 o’clock

Angle unverified · feature edges uncertain · Rectangular luminous baton partially occluded by the minute hand.

S019 · 10 o’clock

Round feature · position check; no unique axis · centre offset -0.1° from clock ray (geometry + segmentation -0.1° to -0.0°) · image-plane only · Unoccluded round luminous marker properly segmented.

S019 · 11 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.2° to -0.2°) · image-plane only · Unoccluded round luminous marker cleanly captured.

S019 · 12 o’clock

Triangular insert · centre placement; precise rotation unmeasured · centre offset -0.3° from clock ray (geometry + segmentation -0.3° to -0.3°) · image-plane only · Luminous coverage verified; this is not a straightness pass. · Final triangle finding: 12 o’clock triangle orientation. S004 and S019 native and corrected close-ups show a slightly rising luminous base toward the right and a small apex-to-base-midpoint lean. · Luminous top-edge direction -1.6° (sensitivity -1.8° to -1.4°); apex-to-base direction -1.9° (sensitivity -1.9° to -1.7°). Image-plane silhouette directions, not physical mounting angles or factory tolerances.

S006 · 1 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.4° to -0.3°) · image-plane only · Round luminous plot is fully captured without occlusion.

S006 · 2 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.3° to -0.3°) · image-plane only · Round luminous plot is visible and unoccluded.

S006 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Cyclops and date window are visible with no luminous insert.

S006 · 4 o’clock

Round feature · position check; no unique axis · centre offset +0.0° from clock ray (geometry + segmentation -0.0° to +0.0°) · image-plane only · Round luminous plot is completely segmented without interference.

S006 · 5 o’clock

Round feature · position check; no unique axis · centre offset -0.1° from clock ray (geometry + segmentation -0.2° to +0.3°) · image-plane only · Round luminous plot is fully isolated and unblocked.

S006 · 6 o’clock

+0.5° luminous image axis · sensitivity +0.4° to +0.6° (geometry + segmentation; not physical tilt) · centre offset +0.1° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Elongated luminous baton is fully visible and unobscured.

S006 · 7 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation +0.2° to +0.5°) · image-plane only · Round luminous plot is completely captured with clean borders.

S006 · 8 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation +0.3° to +0.4°) · image-plane only · Round luminous plot is cleanly segmented without hand occlusion.

S006 · 9 o’clock

Angle unverified · local axis not confirmed · Elongated rectangular marker is partially occluded by the minute hand.

S006 · 10 o’clock

Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to +0.2°) · image-plane only · Round luminous plot is unoccluded and completely segmented.

S006 · 11 o’clock

Round feature · position check; no unique axis · centre offset -0.3° from clock ray (geometry + segmentation -0.4° to -0.2°) · image-plane only · Round luminous plot is cleanly isolated without interference.
