Gallery QC

AE169281/9.23

GL candidate · automated visual QC

S001 · Camera geometry corrected. Image rotated approximately 0.1° clockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using the printed ticks’ inner tips after broad ink detection. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Visible cosmetic QC is acceptable. Dial layout and triangle edge evidence do not support a consequential alignment defect.

Dial alignment and bar axis versus placement

S001 shows a coherent dial layout. Its unobstructed 6 o’clock luminous bar has an image-model axis offset of -0.5° (geometry-plus-segmentation sensitivity -0.6° to -0.2°). Separately, radial placement is 0.2° (sensitivity 0.0° to 0.2°). Other supplied local measurements are withheld. The small visible luminous-axis offset is not perfect straightness, but does not establish a consequential metal-frame mounting defect.

S001 S012

12 o’clock triangle orientation

At S001/hour 12, native frame and luminous edges appear balanced; the corrected base is approximately level with a centered inward apex. At S012/hour 12, the native base slopes with the oblique view, while corrected edges again show a level-looking base and balanced taper. Unequal bevel brightness is visible. Neither source's native-plus-corrected edge evidence supports a repeated triangle lean.

S001 S012

Hands, printing and date

S001 shows intact-looking hands and legible principal dial printing, with shadows beneath the hands. A luminous marker occupies 3 o’clock and no date aperture is present. No compelling hand or printing defect is visible.

S001 S012

Raised bezel

S001's native bezel view shows the top luminous insert and readable numerals. Visible numeral spacing relative to nearby bezel ticks shows no compelling local anomaly, although the view is tilted and reflective. No bezel defect is supported.

S001

Exterior finish

Visible case areas in S001 are reflective and partly film-covered. Exterior reviews likewise report protective material and strong reflections on bracelet, clasp and case surfaces without a supported damage concern. No compelling finish defect is established, but covered surfaces and fine scratches remain unverified.

S001 S005 S006 S008 S009 S013

Timing and operation

No timing screen or numerical timing snapshot is supplied. S001 and S012 are still photographs. Rate, amplitude, beat error and movement health are unverified.

S001 S012

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S001 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S001 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S012 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

Supporting dial views

Additional camera references

S012

Camera geometry corrected

Position and angle checks

2 dial views · 24 checks

S001 · 1 o’clock

Round feature · position check; no unique axis · Round luminous marker with metal bezel edge contamination in mask.

S001 · 2 o’clock

Round feature · position check; no unique axis · Round luminous marker with minor metallic frame inclusion along border.

S001 · 3 o’clock

Angle unverified · local axis not confirmed · Rectangular luminous baton with frame bleed along the upper and lower edge.

S001 · 4 o’clock

Round feature · position check; no unique axis · Round luminous marker with metal rim artifact in the segmentation mask.

S001 · 5 o’clock

Round feature · position check; no unique axis · Round luminous plot showing metal border contamination.

S001 · 6 o’clock

-0.5° luminous image axis · sensitivity -0.6° to -0.2° (geometry + segmentation; not physical tilt) · centre offset +0.2° from clock ray (geometry + segmentation +0.0° to +0.2°) · image-plane only · Vertical rectangular luminous baton clearly captured without significant frame intrusion.

S001 · 7 o’clock

Round feature · position check; no unique axis · Round luminous marker with edge rim reflections included in mask.

S001 · 8 o’clock

Round feature · position check; no unique axis · Round luminous plot showing silver frame ring segment included.

S001 · 9 o’clock

Angle unverified · local axis not confirmed · Horizontal rectangular luminous marker with upper metal edge contamination.

S001 · 10 o’clock

Round feature · position check; no unique axis · Round luminous plot with reflective metallic bezel segment captured.

S001 · 11 o’clock

Round feature · position check; no unique axis · Round luminous marker with partial border reflection attached to the mask.

S001 · 12 o’clock

Angle unverified · feature edges uncertain · Luminous mask incomplete; numerical angle withheld. · Final triangle finding: 12 o’clock triangle orientation. At S001/hour 12, native frame and luminous edges appear balanced; the corrected base is approximately level with a centered inward apex.

S012 · 1 o’clock

Round feature · position check; no unique axis · Round plot is visible with slight edge metal inclusion.

S012 · 2 o’clock

Round feature · position check; no unique axis · Circular marker is unoccluded with minor border frame artifact.

S012 · 3 o’clock

Angle unverified · local axis not confirmed · Rectangular baton is visible with boundary mask leakage.

S012 · 4 o’clock

Round feature · position check; no unique axis · Round lume marker shows adjacent minute hand tip nearby.

S012 · 5 o’clock

Round feature · position check; no unique axis · Circular plot is clear with slight frame reflection captured.

S012 · 6 o’clock

Angle unverified · local axis not confirmed · Vertical baton marker is visible without hand obstruction.

S012 · 7 o’clock

Round feature · position check; no unique axis · Circular index is unobscured with slight edge contamination.

S012 · 8 o’clock

Round feature · position check; no unique axis · Round marker is clear with minor bezel rim mask spill.

S012 · 9 o’clock

Angle unverified · local axis not confirmed · Horizontal baton is unobscured with frame contour included.

S012 · 10 o’clock

Round feature · position check; no unique axis · Circular lume marker is unoccluded with partial metal frame mask.

S012 · 11 o’clock

Round feature · position check; no unique axis · Round index is fully visible with slight edge border.

S012 · 12 o’clock

Source gallery

14 photos · 0 videos

14 photos · 0 videos in the saved gallery. Repeated views are not independent confirmation.
