Gallery QC
RECOMMENDATION
S007 shows orderly marker placement. The verified luminous axes are 0.4° at 6 o’clock (sensitivity 0.2° to 0.5°) and -0.8° at 9 o’clock (-0.8° to -0.7°). Separately, placement offsets are 0.2° (0.1° to 0.2°) and 0.2° (0.1° to 0.2°), respectively. These are small image-only offsets, not perfectly straight axes or measurements of metal-frame mounting.
S007In S007’s native and corrected triangle close-ups, the base is approximately level and the side edges converge toward an apex approximately beneath the base midpoint. The luminous insert and metal rim show differing highlights but no convincing shared lean. The edge evidence supports the supplied no-visible-concern review, without relying solely on centroid placement or the radial reference.
S007S007 shows intact-looking hands and a legible displayed date of 12 without obvious clipping. The minute hand covers portions of the lower dial text, and the seconds hand crosses the 4 o’clock plot. Visible hands and date are acceptable.
S007The S007 native bezel view shows readable exposed numerals, ticks and the luminous zero marker. Reflection affects the right sector, and the glove partly covers the lower numeral. No convincing local spacing or printing defect is visible.
S007S009 shows protective material along the case and bracelet. S010 shows film edges and fine surface marks across reflective clasp areas. The repeated film limitation is supported, but the marks cannot reliably be assigned to underlying metal damage.
S009 S010No timing readings or operating video are supplied; S007 is a static dial photograph. Rate, amplitude, beat error and movement health are unverified.
S007Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.
Round feature · position check; no unique axis · centre offset +0.4° from clock ray (geometry + segmentation +0.3° to +0.5°) · image-plane only · Round lume plot fully visible and cleanly masked without occlusion.
Round feature · position check; no unique axis · centre offset +0.1° from clock ray (geometry + segmentation +0.0° to +0.2°) · image-plane only · Round lume plot fully visible and cleanly masked without occlusion.
Date window · no luminous marker or bar-axis measurement · Date window aperture with cyclops magnifier present instead of luminous marker.
Angle unverified · feature edges uncertain · Round lume plot occluded by the thin seconds hand needle. · amber outlines are candidate reflective edges
Round feature · position check; no unique axis · centre offset +0.0° from clock ray (geometry + segmentation -0.3° to +0.1°) · image-plane only · Round lume plot completely visible with minute hand tip pointing just above it.
+0.4° luminous image axis · sensitivity +0.2° to +0.5° (geometry + segmentation; not physical tilt) · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Rectangular luminous baton fully unobstructed and cleanly masked.
Round feature · position check; no unique axis · centre offset +0.2° from clock ray (geometry + segmentation -0.0° to +0.3°) · image-plane only · Round lume plot fully visible without occlusion.
Round feature · position check; no unique axis · centre offset +0.4° from clock ray (geometry + segmentation +0.4° to +0.5°) · image-plane only · Round lume plot fully visible without occlusion.
-0.8° luminous image axis · sensitivity -0.8° to -0.7° (geometry + segmentation; not physical tilt) · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Horizontal rectangular luminous baton fully visible and cleanly segmented.
Round feature · position check; no unique axis · centre offset +0.1° from clock ray (geometry + segmentation +0.1° to +0.2°) · image-plane only · Round lume plot completely visible and unoccluded.
Round feature · position check; no unique axis · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Round lume plot fully visible without obstruction.
Angle unverified · feature edges uncertain · centre offset -0.2° from clock ray (geometry + segmentation -0.3° to -0.2°) · image-plane only · Luminous coverage verified; this is not a straightness pass. · Final triangle finding: 12 o’clock triangle orientation. In S007’s native and corrected triangle close-ups, the base is approximately level and the side edges converge toward an apex approximately beneath the base midpoint.
14 photos · 0 videos in the saved gallery. Repeated views are not independent confirmation.
