Gallery QC

8688-809-1

GL candidate · automated visual QC

S013 · Camera geometry corrected. Image rotated approximately 0.2° counterclockwise at the dial centre; perspective and unequal image scaling normalized to a circular dial reference using detected printed tick centres. Recentered and resampled to 1900 × 1900 pixels. No correction for crystal refraction or raised bezel/hand geometry. Extended rays are visual dial references only; they do not correct or measure the raised bezel.

RECOMMENDATION

Acceptable visible QC in the supplied photos, with no supported major cosmetic concern. Dial layout and the unobscured 12 o’clock triangle look coherent; the S001 triangle is hand-covered, not contradictory evidence.

Dial placement and bar axes

S013 shows a coherent marker layout. S001’s completed diagnostic review validates the luminous components at 6 and 9: supplied image axes are respectively -0.6° (sensitivity -1.8° to -0.1°) and -0.3° (-1.1° to 0.4°). Separately, placement offsets are 0.2° (0.1° to 0.3°) and -0.5° (-0.6° to -0.4°). S013 bar masks are incomplete and veto numerical use. These are small image-only luminous-axis and placement offsets, not perfectly zero axes or established metal-frame mounting defects.

S001 S013

12 o’clock triangle orientation

S013’s native and corrected close-ups show a broadly level base and balanced converging edges in both luminous insert and metal frame, without convincing tilt. S001’s native and corrected close-ups have hands covering the central insert and apex. S013 edge evidence supports no visible orientation concern, without establishing perfect symmetry or a physical angle.

S013 S001

Hands, printing and date

S013 shows intact-looking hands and a legible date 26 contained within the aperture. A hand and its shadow cross part of the lower dial lettering; the 8 o’clock marker is partly covered by the GMT hand. No supported malformed-text or visible hand defect.

S013 S001

Raised bezel

S013’s native bezel view shows readable numerals and surrounding dots, with perspective and reflections. No convincing local spacing defect is apparent. No bezel defect claim is supported.

S013 S002 S003

Case and bracelet finish

S013 shows reflective case surfaces. Exterior reviews describe reflections, protective coverings and ambiguous surface lines, particularly on the bracelet and clasp. No repeated supported damage concern is established, but underlying finish cannot be fully verified through coverings or from review prose alone.

S013 S007 S010 S011 S012

Timegrapher snapshot

Rate +3 s/day; Amplitude 287 °; Beat error 0.1 ms; Lift angle 52 °; Beat rate 28800 bph; Interval 12 s Displayed amplitude depends on the selected lift angle; the correct setting for the installed movement is not verified. Winding, stabilization, position and recording duration are unknown. Two transcriptions of one source are not independent timing measurements.

S015

Red ring: printed dial-track reference. Red dashed rays continue the dial positions across the bezel for visual comparison only; they do not correct, measure or set a tolerance for the raised bezel or cyclops. Cyan crosshairs mark the dial’s cardinal axes. Green lines show released luminous-insert axes, and amber outlines show candidate reflective edges. Positive angles are clockwise; negative angles counterclockwise. Sensitivity ranges are not confidence intervals. Native close-ups preserve the source view.

Detail checks

S013 · Native full-bezel context. Raised bezel features assessed visually in this original camera view

S013 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S001 · 12 o’clock triangular insert: native crop and corrected dial reference. Amber outline, when present, is a candidate luminous silhouette

S015 · Full timegrapher source frame; screen-crop coverage is unverified. Readings describe this snapshot only.

Supporting dial views

Additional camera references

S001

Camera geometry corrected

Position and angle checks

2 dial views · 24 checks

S013 · 1 o’clock

Angle unverified · local axis not confirmed · Seconds hand crosses circular lume marker.

S013 · 2 o’clock

Round feature · position check; no unique axis · Lume plot shows an incomplete segmentation mask.

S013 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window frame partially masked as lume.

S013 · 4 o’clock

Round feature · position check; no unique axis · Lume mask failed to extract the circular plot.

S013 · 5 o’clock

Round feature · position check; no unique axis · Lume plot shows incomplete mask coverage.

S013 · 6 o’clock

Angle unverified · feature edges uncertain · Baton lume insert shows edge-only thresholding.

S013 · 7 o’clock

Round feature · position check; no unique axis · Circular lume insert has an incomplete mask.

S013 · 8 o’clock

Angle unverified · feature edges uncertain · GMT hand tip occludes the circular marker. · amber outlines are candidate reflective edges

S013 · 9 o’clock

Angle unverified · feature edges uncertain · Horizontal baton mask is hollowed out.

S013 · 10 o’clock

Round feature · position check; no unique axis · Circular lume marker is not fully captured.

S013 · 11 o’clock

Round feature · position check; no unique axis · Circular lume plot shows edge mask segmentation.

S013 · 12 o’clock

Angle unverified · feature edges uncertain · Luminous mask incomplete; numerical angle withheld. · Final triangle finding: 12 o’clock triangle orientation. S013’s native and corrected close-ups show a broadly level base and balanced converging edges in both luminous insert and metal frame, without convincing tilt. · amber outlines are candidate reflective edges

S001 · 1 o’clock

Round feature · position check; no unique axis · Round lume plot includes frame edge artifacts in the segmentation.

S001 · 2 o’clock

Angle unverified · feature edges uncertain · Round lume insert is fully selected without occlusion or frame intrusion.

S001 · 3 o’clock

Date window · no luminous marker or bar-axis measurement · Date window aperture displaying numerals rather than a luminous marker.

S001 · 4 o’clock

Round feature · position check; no unique axis · centre offset +0.5° from clock ray (geometry + segmentation +0.3° to +0.6°) · image-plane only · Circular luminous insert is cleanly isolated without frame inclusion.

S001 · 5 o’clock

Round feature · position check; no unique axis · centre offset +0.3° from clock ray (geometry + segmentation +0.2° to +0.4°) · image-plane only · Round lume plot is cleanly extracted with no occlusion.

S001 · 6 o’clock

-0.6° luminous image axis · sensitivity -1.8° to -0.1° (geometry + segmentation; not physical tilt) · centre offset +0.2° from clock ray (geometry + segmentation +0.1° to +0.3°) · image-plane only · Rectangular luminous baton is completely segmented without frame contamination.

S001 · 7 o’clock

Round feature · position check; no unique axis · centre offset -0.5° from clock ray (geometry + segmentation -0.6° to -0.4°) · image-plane only · Round lume insert is cleanly isolated from surrounding metal frame.

S001 · 8 o’clock

Round feature · position check; no unique axis · centre offset -0.8° from clock ray (geometry + segmentation -0.9° to -0.3°) · image-plane only · Round lume plot is cleanly masked without adjacent interference.

S001 · 9 o’clock

-0.3° luminous image axis · sensitivity -1.1° to +0.4° (geometry + segmentation; not physical tilt) · centre offset -0.5° from clock ray (geometry + segmentation -0.6° to -0.4°) · image-plane only · Horizontal luminous baton is fully captured without border bleed.

S001 · 10 o’clock

Round feature · position check; no unique axis · Round lume mask includes fragments of the outer metal bezel ring.

S001 · 11 o’clock

Round feature · position check; no unique axis · Segmentation leaks into the surrounding metal frame along the perimeter. · amber outlines are candidate reflective edges

S001 · 12 o’clock

Source gallery

15 photos · 0 videos

15 photos · 0 videos in the saved gallery. Repeated views are not independent confirmation.
